SilkScreen printing in surface treatment

Definition of Silk Screen Printing:

Silk screen printing, also known as screen printing, refers to using a silk screen as the plate base and through the method of photosensitive plate-making. Based on the basic principle that the mesh of the graphic part of the silk screen printing plate can allow ink to pass through while the mesh of the non-graphic part cannot, printing is carried out to produce a silk screen printing plate with graphics and text.

Principle of Silk Screen Printing:

The basic principle of printing is to use the mesh holes in the graphic and textual parts of the screen printing plate to allow ink to pass through, while the mesh holes in the non graphic and textual parts do not allow ink to pass through. During printing, ink is poured onto one end of the screen printing plate, and a scraper is used to apply a certain pressure to the ink area on the screen printing plate while moving towards the other end of the screen printing plate. The ink is squeezed onto the substrate from the mesh of the graphic and textual parts by the scraper during movement.

Components of Silk Screen Printing:

Silk screen printing consists of five major elements: the silk screen printing plate, the squeegee blade, the ink, the printing table, and the substrate.

Technological Process of Silk Screen Printing:

Stretching the Screen - Degreasing - Drying - Peeling off the Base Film - Exposure - Development - Drying - Plate Revision - Sealing the Screen

Advantages of Silk Screen Printing:

(1) Not Limited by the Size and Shape of the Substrate
(2) Soft Plate Surface and Low Printing Pressure
(3) Strong Ink Layer Coverage
(4) Applicable to Various Types of Inks
(5) Strong Resistance to Sunlight
(6) Flexible and Diverse Printing Methods
(7) Convenient Plate-making, Inexpensive, and Easy to Master the Technology
(8) Strong Adhesion
(9) It can be done by pure manual silk screen printing or machine printing.
(10) Suitable for Long-term Display, and Outdoor Advertisements are Expressive
